Mac Studio 2025: Complete Comparison 🔥 New or Old Model? Find Out Now!
Apple has refreshed the Mac Studio twice since its launch in 2022. So, should you upgrade? And is it worth buying an older model? 🤔
The main improvement of the new Mac Studio is its chip, which goes from the M2 Max and M2 Ultra to the M4 Max and M3 Ultra. Compared to its predecessor, the new Mac Studio is up to a 75% faster and has 2x faster graphics. It also includes up to 512GB of memory and 16GB of storage, just like Thunderbolt 5 connectivity. ⚡
Check out the breakdown of every new feature, change, and improvement added with the latest Mac Studio compared to its predecessors below:
| Mac Studio (2022) | Mac Studio (2023) | Mac Studio (2025) |
|---|---|---|
| Apple M1 Max or M1 Ultra chip | Apple M2 Max or M2 Ultra chip | Apple M4 Max or M3 Ultra chip |
| M1 Max: 10-core CPU (8 performance cores, 2 efficiency cores) M1 Ultra: 20-core CPU (16 performance cores, 4 efficiency cores) | M2 Max: 12-core CPU (8 performance cores, 4 efficiency cores) M2 Ultra: 24-core CPU (16 performance cores, 8 efficiency cores) | M4 Max: Up to 16-core CPU (12 performance cores, 4 efficiency cores) M3 Ultra: Up to 32-core CPU (24 performance cores, 8 efficiency cores) |
| M1 Max: GPU up to 32 cores M1 Ultra: GPU up to 64 cores | M2 Max: GPU up to 38 cores M2 Ultra: GPU up to 76 cores | M4 Max: GPU up to 40 cores M3 Ultra: GPU up to 80 cores |
| Hardware-accelerated ray tracing | ||
| AV1 decoding | ||
| M1 Max: 16-core Neural Engine (11 TOPS) M1 Ultra: 32-core Neural Engine (22 TOPS) | M2 Max: 16-core Neural Engine (15.8 TOPS) M2 Ultra: 32-core Neural Engine (31.6 TOPS) | M4 Max: 16-core Neural Engine (38 TOPS) M3 Ultra: 32-core Neural Engine (76 TOPS) |
| M1 Max: Video decoding engine M1 Ultra: Two video decoding engines | M2 Max: Video decoding engine M2 Ultra: Two video decoding engines | M4 Max: Video decoding engine M3 Ultra: Two video decoding engines |
| M1 Max: Two video encoding engines M1 Ultra: Four video encoding engines | M2 Max: Two video encoding engines M2 Ultra: Four video encoding engines | M4 Max: Two video encoding engines M3 Ultra: Four video encoding engines |
| M1 Max: Two ProRes encoding and decoding engines M1 Ultra: Four ProRes encoding and decoding engines | M2 Max: Two ProRes encoding and decoding engines M2 Ultra: Four ProRes encoding and decoding engines | M4 Max: Two ProRes encoding and decoding engines M3 Ultra: Four ProRes encoding and decoding engines |
| M1 Max: 32GB or 64GB memory M1 Ultra: 64GB or 128GB memory | M2 Max: Memory of 32GB, 64GB, or 96GB M2 UltraMemory: 64GB, 128GB, or 192GB | M4 MaxMemory: 36GB, 48GB, 64GB, 128GB M3 Ultra: Memory of 96GB, 256GB, or 512GB |
| M1 Max: 400GB/s memory bandwidth M1 Ultra: 800GB/s memory bandwidth | M2 Max: 400GB/s memory bandwidth M2 Ultra: 800GB/s memory bandwidth | M4 Max: Memory bandwidth up to 546GB/s M3 Ultra: 819GB/s memory bandwidth |
| 512GB, 1TB, 2TB, 4TB, or 8TB SSD storage | M2 Max: 512GB, 1TB, 2TB, 4TB, or 8TB SSD storage M2 Ultra: 1TB, 2TB, 4TB, or 8TB SSD storage | M4 Max: 512GB, 1TB, 2TB, 4TB, or 8TB SSD storage M3 Ultra: 1TB, 2TB, 4TB, 8TB, or 16TB SSD storage |
| M1 Max: Four Thunderbolt 4 ports and two USB-C ports M1 Ultra: Six Thunderbolt 4 ports | M2 Max: Four Thunderbolt 4 ports and two USB-C ports M2 Ultra: Six Thunderbolt 4 ports | M4 Max: Four Thunderbolt 5 ports and two USB-C ports M3 Ultra: Seis puertos Thunderbolt 5 |
| HDMI 2.0 port | HDMI 2.1 port | HDMI 2.1 port |
| Support for up to four Pro Display XDRs and one 4K display | Support for up to eight 4K, six 6K, or three 8K displays | Support for up to eight 4K, eight 6K, or four 8K displays |
| 3.5mm headphone jack | 3.5mm headphone jack with advanced support for high-impedance headphones | 3.5mm headphone jack with advanced support for high-impedance headphones |
| Wi-Fi 6 802.11ax | Wi-Fi 6E 802.11ax | Wi-Fi 6E 802.11ax |
| Bluetooth 5.0 | Bluetooth 5.3 | Bluetooth 5.3 |
| Released in March 2022 | Released in June 2023 | Launched in March 2025 |
Only 2022 Mac Studio users pushing their machines to the limit with tasks like 3D rendering 🎨, high-resolution video editing 🎬, machine learning workflows 🤖, or large-scale software development 💻 should consider this. update to the model of 2025.
HeMac Studio from 2025 features a considerable leap in performance 🚀, especially with the M4 Max and M3 Ultra chips, which offer noticeably better graphics performance 🎮, more powerful GPUs with hardware-accelerated ray tracing ✨, a significantly faster Neural Engine ⚡, and support for up to 512GB of memory and Thunderbolt 5 ⚙️. These improvements dramatically improve workflows that require extreme parallel processing, faster memory access, or wide external monitor setups 🖥️.
If your current 2022 Mac Studio ever feels like a bottleneck 🐢, or if you’re gearing up to work on increasingly complex projects in the coming years 📈, upgrading is likely worth it ✅. However, for users whose workloads remain within the capabilities of the M1 Max or M1 Ultra—especially those focused on less GPU-intensive tasks 🎯—the improvements may not justify the cost at this time 💸.
Upgrading from the 2023 Mac Studio to the 2025 model is likely worth it for many. fewer users, simply because the performance increases, although significant on paper, will make less difference in the real world for most professionals already using the M2 Max or M2 Ultra chip, as the 2023 model is still exceptionally capable. 💻⚡
However, there are some particular cases where the upgrade might be justified, especially for users working with large local language models or intensive AI workloads, where the improved Neural Engine in the M4 Max or M3 Ultra can offer significant benefits. 🤖🚀
Similarly, users who rely on extremely high memory capacities or bandwidth, or those building systems around Thunderbolt 5 support and AV1 decoding, could see tangible improvements that justify the cost. 🔌📈
Still, for the vast majority of users, especially those in video production, app development, or general professional workflows, the 2023 Mac Studio is still more than enough for the foreseeable future, making upgrading to 2025 more of a luxury than a necessity. 😌🎬
The 2022 and 2023 Mac Studio models are still highly recommended, especially if you can find them refurbished or used for a good price. 🔥 Both offer exceptional performance that remains very competitive even in 2025, with the M1 Ultra and M2 Ultra delivering plenty of CPU and GPU power, high memory bandwidth, and dedicated media engines that smoothly handle demanding tasks like video editing 🎬, music production 🎵, 3D rendering, and software development 💻.
While they don't include recent enhancements like Thunderbolt 5, hardware-accelerated ray tracing, or the improved performance of the Neural Engine found in the 2025 models, these features are primarily useful for users with very specific, future-oriented needs.
For most professionals and power users, especially those upgrading from Intel Macs or M1-based systems, the 2022 and 2023 models remain an exceptional choice ⚡, often representing the best balance of performance and price when purchased refurbished or used. 💰
